Product Description
JESCO LIGHTING MMGGU1050-4AW 4-Light Line Voltage New Construction Modulinear Directional Recessed Lighting Fixture
JESCO 4-Light Line Voltage New Construction Modulinear Directional Recessed Lighting Fixture. This New Construction recessed fixture is comprised of separate housing and trim. The trim design allows use in ceilings up to 2?ö thick, and GU10 sockets mean that no transformer is required. This makes dimming infinitely easier for both halogen and LED lamp applications.
Housing can be positioned anywhere along the hanger bars
3/4?ö overlap flanges, along with ?ôpull-tight?ö torsions springs allows for minor cutting errors in the ceiling
Self-resetting thermal protector ensures that fixture is deactivated in case of overheating.
Double-gimbal construction ensures that lamps can be aimed at virtually any point below the ceiling.
Butterfly hanger brackets allow for the fixture height to be easily adjusted to the correct height.
Trimless ?ômud in?ö option available.
Aiming - Inner Gimbal: 30°, Outer Gimbal: 30°. Fits up to 2?ö ceiling depth
The housing is constructed out of a heavy gauge cold rolled steel and powder coated to ensure corrosion resistance,
Junction box is listed for for thru branch circuit wiring (Max of 8 #12 AWG 90°C branch circuit conductors). A variety of different sized knockouts provide for different wiring options.
Designed to be installed with overlap flange trim. Universal mounting brackets allow the use of conduit, HB or FB bar stock, or ?ôC?ö channel bars. Consult factory for possible use in trimless ?ômud-in?ö installations. Non-IC means 3?ö clearance from any insulation on all sides must be maintained.
Fixture Dimension(in): 28.25(L) x 5.75(W) x 6.25(H)
Bulb: (4)50W GU10 Base(Not Included)
Input Voltage: 120V
Certifications: UL & CUL Listed.
Finish: AW White Trim, White Gimbal
